Isolated USB 3.2 Gen2 4-Port Hub

Isolated USB 3.2 Gen2 4-Port Hub

USB3-GEN2iH

Isolated USB 3.2 Gen2 4-Port Hub protects PC or Laptop while connecting USB peripherals which is wired to high voltage. This small, industrial grade isolator hub is very easy to use and provides a high-voltage barrier protection against surges, noise and ground loop errors. It is suitable for using in sensitive applications like automotive measurements. Isolated USB 3.2 Gen2 4-Port Hub provides a high-voltage isolation barrier between computer and its connected USB devices. The isolation protects equipment from electrical over-voltages and transient voltage spikes, by eliminating ground loop currents flowing between the PC and USB devices which can cause damage and inaccurate measurements. Additionally, isolation minimizes conducted noise from static discharge, magnetic fields and radio frequency interference.
  •  Feature
  •  Specification
  •  Download
Features:
➢ Isolation 2000VDC between USB host and USB devices.
➢ Supports USB 3.2 Gen2 data transfer rates up to 10 Gbps.
➢ Fully Compliant with USB specification 1.1, 2.0, 3.2 Gen1, 3.2 Gen2.
➢ Isolated host power through a DC-to-DC converter.
➢ Compatible with all USB-C and Thunderbolt 3 devices.
➢ Class 3A contact ESD performance per ANSI / ESD STM5.1-2007; Supports ±15kV ESD protection on each port.
➢ High common-mode transient immunity :>50 kV/μs.
➢ Auto-Negotiation of Link Speed.
➢ The USB 3.2 Gen2 Type-C ports comply with USB Battery Charging Spec 1.2; and enable to provide up to 1.5A (CDP mode) output current on each port.
➢ Compatible OS thru USB 2.0: Windows 98SE / ME / 2000 / XP / Vista / 7 / 8 / 8.1 / 10 / 11; Mac OS 8.6 or higher.
➢ Compatible OS thru USB 3.2 Gen1 and 3.2 Gen2: Windows 7 / 8 / 8.1 / 10 / 11; Mac OS X Mountain Lion or higher.
